CQYB/II-150N SOLAS Inflatable Life Jacket

The CQYB/II-150N is a twin-chamber inflatable life jacket manufactured
to SOLAS and EU MED requirements, type-approved by RINA and CCS. Designed
for crew and passengers on merchant vessels and offshore installations, it
provides a minimum of 150N buoyancy and is engineered to turn most wearers
— including an unconscious wearer — face-up, with a face plane angle of
40° or greater.

Dual 33g CO₂ cylinders inflate the jacket automatically on immersion or
manually by the wearer, with full inflation in under five seconds. The
double air chamber provides redundancy: each chamber independently holds
the wearer. At under 1.5 kg, the jacket is light enough for continuous
wear on deck.

Technical Specifications

Standard	SOLAS / EU MED
Type approval	RINA, CCS
Buoyancy	≥ 150 N
Air chamber	Double
Inflation	Manual & automatic, twin 33g CO₂ cylinders
Inflation time	≤ 5 s
Fabric	400D Oxford + 0.15 mm TPU
Weight	≤ 1.5 kg
Size	Adult universal
Face plane angle	≥ 40°
Trunk angle	≥ 30°
Freeboard	≥ 12 mm
Buoyancy loss	≤ 5% in 24 h
Floating duration	≥ 48 h
Operating temperature	−30 °C to +65 °C
Supplied with	Whistle, reflective tape, CO₂ cylinders, manual & automatic inflation systems, life jacket light

Certification

Type approval certificates for this model are provided during
commercial discussion. State your flag state or destination market in the
inquiry and we will confirm the applicable documentation.
